Bicor™ HLD 20.0

Oriented Polypropylene Film

Product Description

Transparent, one side very low heat sealable (80°C), one side treated, heat sealable BOPP film. It has an ultra low heat seal threshold sealing layer, as well as tailored and controlled slip properties to further enhance its high speed running capabilities.

Key Features

  • Transparent, low haze and excellent gloss
  • Tailored and controlled hot slip properties, up to 60°C
  • Ultra low heat sealing threshold (80°C) layer for high speed HFFS packaging machines
  • Corona treated side contributes to improve printing and lamination
  • Good moisture barrier
  • Not suitable for boost treatment

General

Availability

  • Europe

Features

  • Broad Seal Range

Applications

  • Biscuits/Cookie/Crackers
  • Confectionery, Gum
  • Confectionery, Sugar
  • Bakery
  • Confectionery, Chocolate
  • Health and Beauty Care

Uses

  • HFFS Flexible Packaging

Appearance

  • Clear/Transparent

Processing Method



    Properties

    PropertyTypical ValueUnitTest Based On
    Yield 54.9m²/kg Internal Method
    Unit Weight 18.2g/m² Internal Method
    Film Thickness 20µm Internal Method
    Gloss (45°)
    At 20° (standard heat-sealable side) 100Gloss Unit Internal Method
    Haze 2% Internal Method
    Tensile Strength at Break
    MD 130Mpa Internal Method
    TD 280Mpa Internal Method
    Elongation at Break
    MD 230% Internal Method
    TD 55% Internal Method
    Heat Seal Range (RDM)
    Low heat-sealable side 80-140°C Internal Method
    Coefficient of Friction 0.3 Internal Method
    Treatment
    Treated Surface >=36dyne/cm Internal Method
    Water Vapor Transmission Rate
    38°C, 90% RH 6.8g/m²/24 hr Internal Method
    Heatseal strength 2.0N/15 mm Internal Method



    Food Contact

    Any further regulatory information on this product (i.e. Food Contact application, Presence/absence of substances, Reach, …) are accessible on the below link: https://www.jindalfilms.com/login-register-docmg/

    Legal Statement

    This product is not intended for or supported for use in pharmaceutical or medical applications requiring compliance with EU or US Pharmacopeia.

    Processing Statement

    Refreshing the surface with corona treatment of the processable side before usage is recommended.

    Contact your Jindal Films Technical Service Representative for processing recommendations and guidelines.

    Footnotes

    • Please contact your Sales Representative for complete country availability.

    Revision date

    • March 15, 2024
