Bicor™ 80MC550

Preliminary

Oriented Polypropylene Film

Product Description

Bicor 80MC550 is a one-side treated OPP film designed for use as the inner layer of a multi-wall bag.

Key Features

  • Excellent ink adhesion
  • Stable COF
  • Excellent bond strength in adhesive and extrusion laminations

General

Availability

  • Latin America
  • North America
  • South America

Features

  • Grease Resistant

Applications

  • Pet Food

Uses

  • VFFS Flexible Packaging

Appearance

  • Clear/Transparent

Processing Method

  • Inner Web Adhesive Lamination
  • Solvent Flexographic Printing
  • Solvent Rotogravure Printing
  • Water-based Flexographic Printing
  • Middle Web Adhesive Lamination


Properties

PropertyTypical ValueUnitTest Based On
Yield 38670in²/lb Internal Method
Film Thickness .79mil Internal Method
Gloss
Untreated Surface 88 Internal Method
Haze 1.2% Internal Method
Tensile Strength at Break
20 in/min pull rate, 2.0 in jaw separation
MD 17000psi Internal Method
TD 33500psi Internal Method
Dimensional Stability
135°C / 275°F, 7 min
MD -4.0% Internal Method
TD -4.0% Internal Method
Elongation at Break
MD 164% Internal Method
TD 56% Internal Method
Crimp Seal Strength
Treated/Treated 350g/in Internal Method
Untreated/Untreated 350g/in Internal Method
Coefficient of Friction
Slip Modified/Slip Modified 0.35 Internal Method
Wetting Tension
Treated Surface 0.80receding cos θ Internal Method
Water Vapor Transmission Rate
100°F, 90% RH 0.46g/100 in²/24 hr Internal Method



Food Contact

Any further regulatory information on this product (i.e. Food Contact application, Presence/absence of substances, Reach, …) are accessible on the below link: https://www.jindalfilms.com/login-register-docmg/

Legal Statement

Contact your Jindal Films Customer Service Representative for potential food contact application compliance (e.g. FDA, EU, HPFB). This product is not intended for use in medical applications and should not be used in any such applications.

Processing Statement

  • 80MC provides excellent printing and lamination performance without having to retreat or prime.  Retreating may cause back-side treatment.

Footnotes

  1. Product may not be available in one or more countries in the identfied Availability regions. Please contact your Sales Representative for complete country availability.
  2. Tested at 38°C (100°F)/100%RH, then calculated to 90%RH with .90 multiplier.

Revision date

  • July 07, 2015
